Paul Reed Smith Wood Library 10 Top Swamp Ash Custom 24 Piezo P24 Flame Maple Neck Brazilian Rosewood Copperhead

24 Frets, Infinite Range of Tones

The Custom 24 Piezo is a 24-fret solidbody piezo-equipped guitar that effortlessly achieves classic humbucker tones and authentic acoustic sounds in one instrument. The added versatility of PRS’s patented tremolo gives musicians a new a unique tool to add to their lineup.

The Custom 24 Piezo has two output jacks, allowing guitarists to plug into their favorite electric or acoustic guitar amp or DI into a soundboard. By utilizing the separate blend control, the tone of the 85/15 pickups can also be combined with the piezo acoustic sounds through a single output. With a nearly infinite range of tones and the added versatility and reliability of PRS’s proprietary tremolo bridge, the Custom 24 Piezo is a perfect “go-to” guitar for players of all kinds.

For 2020, PRS has updated this model with TCI-tuned pickups and nitro over celluose (CAB) finish.

Pickup Switching Positions

Position One: Bridge humbucker
Position Two: Bridge humbucker with neck singlecoil, in parallel
Position Three: Bridge and neck humbuckers
Position Four: Neck singlecoil with bridge singlecoil, in parallel
Position Five: Neck humbucker

ModelPRS Wood Library 10 Top Custom 24 Piezo FN+BRZ
BuilderPaul Reed Smith - PRS
Body TypeSolid Body
Top Wood10 Top Flame
Body WoodSwamp Ash
Finish TypeNitro over celluose (CAB) finish
Finish ColorCopperhead
Back FinishNitro over celluose (CAB) finish
BindingScraped Maple Binding
Neck WoodFlame Maple
FingerboardBrazilian Rosewood
Neck CarvePattern Regular
Scale Length25''
Neck Dimensions26/32" Depth @ Nut
Neck Radius10''
Nut Width1 11/16"
Nut MaterialBone
Neck FinishGloss
Inlays1-Piece Green Ripple Abalone PRS Birds
Side DotsDots
HeadstockBrazilian Rosewood Veneer Headstock with PRS Logo
Neck Pickup58/15 LT (Covered)
Bridge Pickup58/15 LT (Covered)
BridgePRS Patented Tremolo, Gen III Piezo
TunersPRS Phase III Locking
ControlsVolume and Tone Control with 5-Way Blade Switch and LR Baggs/PRS Piezo (3-way Selector and Blend Knob)
Case PRS Artist Package Grade Brown Paisley Case
Weight7.75 Pounds (7 lbs 12 oz)
